tem |
Specifications |
Voltage Frequency
|
For Frame size 160L and Less: 220/380/415V-50Hz/
(Above 132S-160L:380/660V-50Hz also available)
|
For Frame size 180M and above : 380/660v – 50Hz
|
Enclosure
|
Totally Enclosed Fan-Cooled Foot Mounted IM B3 and IM V1 (Non-Explosion Proof)
|
Degree of Protection
|
IP55
|
Insulation Class
|
Class F
|
Time Rating
|
S1 (Continuous)
|
Direction of Rotation
|
CCW (Counter Clockwise) viewed from shaft-end side
|
Frame Material
|
Frame size 71 and 80M Steel
|
Frame size 90L – 160L : Aluminum
|
Frame size 180M and above : Cast Iron
|
Ambient Condition
|
Ambient Temperature : -15 – 40 C
|
Ambient Humidity : 90% or Less
|
Above Sea Level : 1000m or Less
|
Environment : No bursting erosive gas or vapor
|
Coating Color
|
Munsell N7
|
Standard
|
IEC 60034-1 / IEC 600034-5
|
Lead Wire Connection
|
6 lead wires with Terminal Block
|
